Product details
Cooling System Capacity |
71.6 L |
Crankcase Capacity |
24.5 L |
Implement Pump Type |
Variable Displacement Piston |
Maximum Net Torque |
1654 N.m at 1100 rpm |
Peak Gross Torque |
1728 N.m at 1200 rpm |
Static Tipping Load |
16164 kg (With Tire Deflection),17421 kg (No Tire Deflection) |
Transmission Oil Capacity |
58.5 L |
Rear Axle Oscillation |
+/-13 degrees |
Front Axle |
Fixed |
Breakout Force |
196 kN |
Displacement |
9.3 L |
Transmission |
4 forward,4 reverse |
Power |
223 kW / 299 HP at 1700 rpm (Net) |
Fuel Tank |
313 L |
Engine Model |
Cat C9.3 ACERT |
Travelling Speed -Reverse |
7.6/15.0/26.5/40.0 km/h |
Travelling Speed -Forward |
6.7/13.1/23.2/40.0 km/h |
Stroke |
149 mm |
Bore |
115 mm |
Gross Power |
251 kW / 337 HP at 1800 rpm |
Loader Bucket Capacity |
2.9-9.9 m3 |
Maximum Operating Weight |
24896 kg |
Model Name/Number |
972M |
Brand |
CAT |
